S h o c k E y e l e t A s s e m b l y
E y e l e t B u s h i n g I n s t a l l a t i o n
Apply a light layer of grease to the outside of the new bushing.
1
Position the shaft eyelet and eyelet bushing between the soft jaws of a
2
vise. Slowly turn the vise handle to begin pressing the eyelet bushing
into the shaft eyelet.
Check the alignment of the bushing as it enters the eyelet. If the
bushing starts to enter the eyelet at an angle, remove the bushing
from the eyelet, regrease the bushing, and repeat this step until the
bushing enters the eyelet straight.
Continue to press the eyelet bushing until it is seated in the shaft
eyelet.
Remove the shock from the vise and repeat the installation process for
the other bushing and eyelet.

Shock Eyelet Assembly
