L o w e r L e g A s s e m b l y
Spray isopropyl alcohol on the upper tubes and clean them with a shop
1
towel.
Apply grease to the inner surfaces of the dust wiper seals.
2
3
Install the lower leg assembly onto the upper tubes and slide it just
Install the lower leg assembly onto the upper tubes and slide it just
enough to engage the upper bushings with the upper tubes.
enough to engage the upper bushings with the upper tubes.
Make sure both wiper seals slide onto the tubes without folding the
outer lip of either seal.
The inside bottom of the lower leg should not contact the spring or
The inside bottom of the lower leg should not contact the spring or
damper shafts. A gap between the shaft ends and the lower leg bolt
damper shafts. A gap between the shaft ends and the lower leg bolt
holes should be visible.
holes should be visible.
NOTI CE
19
Lower Leg Assembly
