SRAM RockShox Deluxe RT3 Service Manual page 10

Insert the threaded rod through the shaft eyelet until the push pin rests
2
against the bushing pin.
Thread the large, open end of the catcher along the rod until it rests on
the end spacer.
Clamp the catcher in a vise or hold it secure with a 13 mm open
3
end or adjustable wrench.
Do not scratch the air can as you turn the wrench.
Use a second 13 mm wrench to thread the push pin along the rod until
it stops against the end spacer.
Unthread the push pin from the threaded rod to remove the end
spacer and the bushing pivot pin.
If the bushing pin does not remove easily, reinsert the threaded rod
4
and push pin through the eyelet shaft.
Thread the large, open end of the catcher along the rod until it rests
against the shaft eyelet.
Use a 13 mm wrench to thread the push pin along the rod until it stops
against the end spacer.
NOTI CE
13 mm
13 mm
Mounting Hardware Removal
13 mm
13 mm
