Outputs - Once-a-Day Pulse
Valcom Series Master Clock
or*
27 26 25 24 23 22
* "or" means one pair of ports or the other. You cannot, for instance, use
port 23 for reset and 27 for power, nor can you use 26 for reset and 24 for
power. You must use the pair 24 AND 23 or the pair 26 AND 27
27 26 25 24 23 22
Master Clock Circuit
Intercom, paging system,
or other device
27 26
or
24 23
