Valcom V-WMCA Series Installation Manual page 26

Outputs - Sync-Wire 24VAC
Valcom Series Master Clock
10 Amp Contact Rating
Clock Circuit
27 26
or
24 23
Neutral
Power
Reset
24VDC
Neutral
Reset
Power
Neutral
Neutral
Power
Reset
27 26 25 24 23 22
or*
27 26 25 24 23 22
White
Black
Yellow
Green
Ground
J1-1
J1-3
Yellow
Orange
Green
Ground
White
Black
Yellow
Green
Ground
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
Clock Circuit 1
* "or" means one pair of ports or
the other. You cannot, for instance,
Clock Circuit 2
use port 23 for reset and 27 for
power, nor can you use 26 for reset
and 24 for power. You must use
the pair 24 AND 23 or the pair
26 AND 27
24VDC Valcom Wired Analog Clock
24VDC Valcom Wired Digital Clock
Red & Blue Wires are NOT provided by Valcom
24VDC Valcom Wired Analog Clock
