Valcom V-WMCA Series Installation Manual page 11

Installing a Master Clock - Rack Mount
5) Attach the power cables to the appropriate port
on the master clock.
7) Install the master clock in the network rack by
inserting screws through the two holes positioned
on either side of the master clock.
5
7
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
6) Use a screwdriver to reattach the master clock
bottom panel.
8) Power the master clock. If the master clock has
been powered, the 7-segment LED screen on the
face of the master clock should illuminate.
*REFER TO THE SECTION "BASIC CONFIGURATION - DHCP AND STATIC
IP" FOR FURTHER INSTRUCTIONS
P. 540-563-2000
F. 540-362-9800
www.valcom.com
6
8
11
