Valcom V-WMCA Series Installation Manual page 13

Installing a Master Clock - Remote Antenna for Rack Mount
1) Use the provided template and a leveling device
to mark four points on the wall.
6 and 15/16in (15.08cm)
3) Insert the wall anchors into the holes.
1
5 and 3/4in
(14.61cm)
3
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
2) Use a drill to drill holes into the wall at the
marked locations.
4) Insert the sheet metal screws into the top two
wall anchors.
