Valcom V-WMCA Series Installation Manual page 15

Installing a Master Clock - Remote Antenna for Rack Mount
9) Hang the remote antenna on the wall screws. Do
this by lining the screws up with the keyhole slots
on the bottom of the box, and slipping the slots on
top of the screws.
11
11) Reattach the bottom panel.
9 10
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
10) Pass the remaining two screws through the
holes in the bottom compartment and into the
wall anchors.
12
12) The transmitter will begin to transmit as soon
as it is powered and is receiving time data from the
master clock.
