SMS Command
#apn
#cellular
#radio
#ethernet
#wan
#serial
#wifi
Note: Arguments in square brackets [ ] are optional. Those in angle brackets < > are values.

Sending an SMS Message

To send an SMS message from the router:
1. Go to SMS > Send SMS to display the Send SMS window.
2. In the Recipient field, enter a phone number and click Add. You can add up to 100 phone numbers.
3. In the Message field, enter a text message up to 160 characters long.
4. Click Send. The system displays a confirmation indicating whether the message has been successfully sent
or not.

Viewing Received SMS Messages

To view received SMS messages from the router:
1. Go to SMS > Received to display the Received SMS window. The messages are sorted by date with the
most recent messages on top. The table shows up to 30 characters for each message.
2. To view the full message, click the eye icon to the right of the message entry.
3. To delete an SMS message, click the trash can icon under Options to the right of the message. A dialog
box asks you to confirm that you want to delete the SMS message. Click OK.
4. To delete all the received SMS messages, click Delete All. A dialog box asks you to confirm that you want
to delete all SMS messages. Click OK.
5. To configure, the receive list to automatically update, check the Auto Refresh box in the upper right
corner.

Viewing Sent SMS Messages

To view sent SMS messages from the router:
®
MultiConnect rCell 100 MTR-EV3 User Guide
Description
get APN string
PPP status
radio status
Ethernet LAN configuration details
WAN transport type and WAN priority configuration
get serial details: Mode (Server or Client), RX bytes, TX
bytes, DCD Status, Protocol, Port (Server mode only),
Server IP Address (Client mode only), and Server Port
(Client Mode only)
get Wi-Fi details: Date and time in format YYYY-MM-DD
HH:MM, mode (WAN or Access Point), MAC address,
status (for WAN mode only), SSID, Security settings (for
Access Point only, None, WEP, WPA, WPA2-PSK, and
WPA/WPA2-PSK)
CONFIGURING SMS
