3. Click Save and Restart to save the change.
For field descriptions see
For information on editing WAN Failover see

Editing Failover Configuration

The device can use the active or passive mode to monitor the Internet availability in WAN. The default condition is
active mode.
Active mode can be type ICMP (ping) or TCP. ICMP periodically pings the designated host at the specified interval.
TCP tries to make a connection to the designated host at the interval specified.
For both ICMP and TCP, if a response is not received, the device switches to the WAN with lower priority. The
device continues to ping the designated host at the interval specified for WAN with the higher priority and
switches back when the ping is successful. When passive mode is enabled, the device switches the WANs when the
network interface is down. The currently active WAN is displayed on the home page under the label WAN
Transport.
To edit failover configuration:
1. Click Setup > WAN Configuration.
2. Under the Options column at the right, click the pencil icon (edit) for the selected WAN. The Failover
Configuration page is displayed.
3. Make the desired changes. Refer to
4. Click Finish.
5. If you are finished making changes, click Save and Restart.

Failover Configuration Fields

Field
Monitoring Mode
Interval
Host Name
Mode Type
TCP Port
ICMP Port

Configuring Dynamic Domain Naming System (DDNS)

This feature allows your router to use a DDNS service to associate a hosted server's domain name with a
dynamically changing internet address. To configure your router to use DDNS:
1. From Setup, select DDNS Configuration.
2. In the Configuration group, check Enabled.
®
MultiConnect rCell 100 MTR-EV3 User Guide
Failover Configuration Fields
Editing Failover Configuration
Failover Configuration Fields
Description
Use the drop-down list to select the mode to connect to the host: PASSIVE or
ACTIVE.
Enter the number of seconds between each check. Default is 60 seconds.
Enter the host name or IP address to use for the check. Default is www.google.com.
Use the drop-down list to select the mode type: ICMP or TCP. Default is ICMP.
(Active Monitoring Mode)
Enter the TCP Port number to connect to the host. (Mode TCP)
Enter the number of ICMP pings to be sent to the specified host. Default is 10.
(Mode ICMP)
CONFIGURING YOUR DEVICE
for details.
