DEFINING TUNNELS
Field
Encryption Method
Phase 1 Encryption
Phase 1 Authentication
Phase 1 Key Group
Phase 2 Encryption
Phase 2 Authentication
Phase 2 Key Group
Enable UID
Local ID
Remote ID
IPSec Tunnel: Advanced
IKE Lifetime
Key Life
Max Retries
Compression
66
Description
Choose an Encryption Method from the following list: 3DES, AES-128,
AES-192, AES-256, or ADVANCED. IKE encryption algorithm is used for
the connection (phase 1 - ISAKMP SA). Based off of phase 1, a secure set
of defaults are used for phase 2, unless the Advanced option is used, in
which case, all components of both phases 1 and 2 are specified by the
user.
If Advanced is selected for Encryption Method, select Phase 1
Encryption from the drop-drown: 3DES, AES-128, AES-192, AES-256,
ANY AES, or ANY.
If Advanced is selected for Encryption Method, select Phase 1
Authentication from the drop-drown: MD5, SHA-1, SHA-2, SHA2-256,
SHA2-384, SHA2-512, or ANY.
If Advanced is selected for Encryption Method, select the Phase 1 Key
Group from the drop-down: DH2 (1024-bit), DH5 (1536-bit), D14 (2048-
bit), DH15 (3072-bit), DH16 (4096-bit), DH17 (6144-bit), DH18 (8192-
bit), DH22 (1024-bit), DH23 (2048-bit), DH24 (2048-bit), and ANY.
If Advanced is selected for Encryption Method, select Phase 2
Encryption from the drop-drown: 3DES, AES-128, AES-192, AES-256,
ANY AES, or ANY.
If Advanced is selected for Encryption Method, select Phase 2
Authentication from the drop-drown: MD5, SHA-1, SHA-2, SHA2-256,
SHA2-384, SHA2-512, or ANY.
If Advanced is selected for Encryption Method, select the Phase 2 Key
Group from the drop-down: DH2 (1024-bit), DH5 (1536-bit), D14 (2048-
bit), DH15 (3072-bit), DH16 (4096-bit), DH17 (6144-bit), DH18 (8192-
bit), DH22 (1024-bit), DH23 (2048-bit), DH24 (2048-bit), and ANY.
Unique Identifier String to enable the Local ID and Remote ID fields.
String Identifier for the local security gateway (optional)
String Identifier for the remote security gateway (optional)
Duration for which the ISAKMP SA exists from successful negotiation to
expiration.
Duration for which the IPsec SA exists from successful negotiation to
expiration.
Number of retry attempts for establishing the IPsec tunnel. Enter zero
for unlimited retries.
Enable IPComp. This protocol increases the overall communication
performance by compressing the datagrams. Compression requires
greater CPU processing.
®
