Chapter 10 – Setting Up Cellular Features

Configuring Cellular

To configure how cellular is used on your device:
1. On the Web Management interface, go to Cellular > Cellular Configuration to display the Cellular
Configuration window. If you choose IPv6 Passthrough mode, you must select Administration > Initial
Setup.
2. Check Enabled.
3. Check and change the Cellular Configuration fields as desired. For field descriptions, see
Configuration
4. Click Submit.
5. To save your changes, click Save and Restart.

Cellular Configuration Fields

Field
General Configuration
Enabled
1
Dial-on-Demand
Diversity
Connect Timeout
Dialing Max Retries
Modem Configuration
Dial Number
Connect String
Dial Prefix
®
MultiConnect rCell 100 MTR-EV3 User Guide
Fields.
Description
Allows the device to establish a cellular connection (Cellular WAN).
Enables the Dial-on-Demand feature. If enabled, the device brings up and
maintains a cellular connection while network activity on the LAN requires
WAN access. The device brings down the cellular connection when outgoing
network traffic ceases for the given Idle Timeout duration. Enable this
feature when Wakeup-on-Call is enabled to allow the device to "sleep" after
it has been "woken up." See Configuring Wakeup-on-Call for more
information.
Allows the use of two antennas to increase receive signal quality. Not all
models support diversity. If diversity is enabled, connect a second cellular
antenna to the AUX port on the device. Otherwise, the cellular performance
of the device may degrade.
The time (in seconds) that the device waits before it deems that the
connection attempt has failed. The value used is the amount of time that
elapses between each dialing retry.
Number of dialing retries allowed; the default is zero, which means an
infinite number is allowed.
The modem dial string is:
The modem response to initiate a PPP connection, usually CONNECT.
The modem AT command that initiates a PPP connection, usually ATDT or
ATD.
*99***1# for GSM/GPRS/non-Verizon LTE devices
#777 for CDMA/EVDO devices
SETTING UP CELLULAR FEATURES
