DEVICE ADMINISTRATION
To turn on the Flash Memory Violation diagnostic that performs a flash memory checksum check to protect the
integrity of device firmware:
1. Check Enabled under Flash Memory Violation.
2. Enter the Flash Memory Check Interval (ranging between 4-24 hours). Default is 24.
3. If you want the system to disable WAN interfaces after a Flash Memory Violation is detected, check
Disable WAN Interfaces under Actions.
4. If you want the system to disable user-defined firewall rules after a Flash Memory Violation is detected,
check Disable User-Defined Firewall Rules under Actions.
After you completed your Self-Diagnostic configuration (selecting any or all of the above):
1. Click Submit.
2. To save changes, click Save and Restart.
If at any time you want to return the device to the default setting, click the Reset to Default button in the bottom
right corner. (This disables or removes all enabled Self-Diagnostic features.)

Configuring Device Access

This section contains configurations that determine how the device can be accessed as well as security features
that decrease susceptibility to malicious activity.
To display the Access Configuration window containing the fields described below, go to Administration > Access
Configuration.

HTTP Redirect to HTTPS

The device allows only secure access to its Web UI. This set of rules automatically redirects HTTP requests to the
device's secure HTTPS port.
Field
Enabled
Port
Via LAN/Ethernet
Via WAN/Cellular

HTTPS

The device provides secure Web UI access to modify its configurations and execute actions.
Field
Port
78
Description
Enables HTTP to HTTPS redirect which automatically
redirects users trying to access the device via HTTP to
HTTPS.
The port on which the device listens for HTTP requests
to redirect.
If checked, the device listens and redirects HTTP
requests to HTTPS from the LAN.
If checked, the device listens and redirects HTTP
requests to HTTPS from the WAN.
Description
The port on which the device will listen for HTTPS
requests.
MultiConnect
®
rCell 100 MTR-EV3 User Guide
