Multitech MultiConnect rCell 100 User Manual page 95

Field
Port
Email
Username
Password
Mail Log Settings
Entries to Keep
Send a Test Email
Address
®
MultiConnect rCell 100 MTR-EV3 User Guide
Description
Enter the port number that the SMTP server uses.
Enter the sender email address. This address will be added as the
sender email address to the sent emails.
Enter the name that can access the SMTP server.
Enter the password that can access the SMTP server.
Enter the desired number of mail log entries that are to be stored
in the router. The range of values is 10 to 1000. If you click Submit,
this setting is not applied to the emails that are in progress or
deferred. Note that logs are not saved on the device. Also, logs do
not persist through power cycles.
To make sure that the SMTP is configured properly, enter a
destination email address, then click Send Test Email.
DEVICE ADMINISTRATION
95
