On-Demand
CR: Three carriage returns must be received from the Bluetooth side before TCP/UDP connection is
established to the remote server.
7. From the Connection Termination drop-down list select a disconnect method for the IP pipe. Options are:
8. Click Submit.
9. To save your changes, click Save and Restart.
To configure security settings:
1. Make sure you select SSL/TLS under Protocol.
2. Under Security Settings, click the Show to the right.
3. By default, the Use default cipher suite is checked. If you accept this default, no other action is needed.
4. Uncheck this box, if you want to select specific TLS versions and Cipher Suites. These fields appear.
5. Select the TLS version. Check either TLSv1.2 or TLSv1.1.
6. Check your preferred Cipher Suite from the following list: ECDHE-RSA-AES256-GCM-SHA384, ECDHE-RSA-
AES256-SHA, DHE-RSA-AES256-GCM-SHA384, AES256-SHA, ECDHE-RSA-AES128-GCM-SHA256, ECDHE-
RSA-AES128-SHA, DHE-RSA-AES128-GCM-SHA256, DHE-RSA-AES128-SHA, and/or AES128-SHA
7. Click Submit.
8. To save your settings, click Save and Restart.
®
MultiConnect rCell 100 MTR-EV3 User Guide
Always On:
Sequence: A sequence of characters received from the Bluetooth side used to disconnect the
IP pipe
Timeout: The IP pipe connection disconnects if the configured timer expires with no data sent
or received
The router immediately connects to the local Bluetooth device. If successful the Status field
displays Connected. If IP Pipe is configured for SERVER, the IP connection is initiated by the
far-end TCP/UDP client.
If Mode is set to Client, the router initiates connections for the far-end TCP/UDP server based
on the configured Connection Activation conditions are met.
