CHAPTER 6 CONFIGURING YOUR DEVICE
Failover mode enables the WAN with the highest priority as displayed on the WAN Configuration page. If the WAN
with priority 1 is disabled or a connection failure is detected, the WAN with priority 2 is automatically selected for
establishing connection to the Internet. Wi-Fi as WAN is priority 1 by default.
1. Click Setup > WAN Configuration.
2. Under Options, click the up and down arrows to change the priority of the appropriate WAN.
3. Click Save and Restart to save the change.
For field descriptions see Failover Configuration Fields
For information on editing WAN Failover see Editing Failover Configuration

Editing Failover Configuration

The router can use the active or passive mode to monitor the Internet availability in WAN. The default condition is
active mode.
Active mode can be type ICMP (ping) or TCP. ICMP periodically pings the designated host at the specified interval.
TCP tries to make a connection to the designated host at the interval specified.
For both ICMP and TCP, if a response is not received, the router switches to the WAN with lower priority. The
router continues to ping the designated host at the interval specified for WAN with the higher priority and
switches back when the ping is successful. When passive mode is enabled, the router switches the WANs when the
network interface is down. The currently active WAN is displayed on the home page under the label WAN
Transport.
To edit failover configuration:
1. Click Setup > WAN Configuration.
2. Under the Options column at the right, click the pencil icon (edit) for the selected WAN. The Failover
Configuration page is displayed.
3. Make the desired changes. Refer to Failover Configuration Fields for details.
4. Click Finish. If you are finished making changes, click Save and Restart.

Failover Configuration Fields

Field
Monitoring Mode
Interval
Host Name
Mode Type
TCP Port
ICMP Port
30
Description
Use the drop-down list to select the mode to connect to the host: PASSIVE or
ACTIVE.
Enter the number of seconds between each check. Default is 60 seconds.
Enter the host name or IP address to use for the check. Default is www.google.com.
Use the drop-down list to select the mode type: ICMP or TCP. Default is ICMP.
(Active Monitoring Mode)
Enter the TCP Port number to connect to the host. (Mode TCP)
Enter the number of ICMP pings to be sent to the specified host. Default is 10.
(Mode ICMP)
®
MultiConnect rCell 100 MTR-H5 User Guide
