CDM-600L Satellite Modem
Front Panel Operation
6.3.4

MONITOR

MONITOR: LIVE-ALARMS
STATISTICS
Select the parameter to Monitor using the [←][→]
6.3.4.1 MONITOR: LIVE-ALARMS
LIVE
ALARMS
An example of an Alarm screen is shown. The highest priority alarm currently active for
each of the four alarm types is shown:
•
•
•
•
6.3.4.2 MONITOR: STORED EVENTS
STORED EVENTS:
#199 FT-FRAME SYNC
An example of a Stored Events screen is shown. Use the [↑] [↓] arrow keys to select
Clear All: YES or NO,
Use the [←][→] arrow keys to select the '#' character on the bottom line to view the log
entries. Scroll backwards or forwards through the entries in the event log, using the [↑]
[↓] arrow keys. Pressing ENTER or CLEAR will take the user back to the previous
menu. The event log can store up to 199 events. When a fault condition occurs, it is time-
stamped and put into the log. Similarly, when the fault condition clears, this is also
recorded.
If the user selects CLEAR ALL, the event log is cleared, and the user is taken directly
back to the previous menu. However, if there are faults present on the unit at this time,
they will be re-time-stamped, and new log entries will be generated.
Note that in accordance with international convention, the date is shown in DAY-
MONTH-YEAR format.
RX-PARAMS
UNIT= NONE
RECV=DEMOD LOCK
Unit
TX
RX
Open Network
CLEAR ALL: YES
then press ENTER.
STORED-EVENTS
AUPC-PARAM
arrow keys, then press ENTER.
NET= NONE
XMT= NONE
(NO,YES)
23/07/01 16:25:24
6–33
Revision 0
MN/CDM600L.IOM
LNB BUC
