CDM-600L Satellite Modem
Front Panel Operation
6.3.1.8
CONFIG: EDMAC
Select either IDLE, MASTER, or SLAVE, using the [↑] [↓] arrow keys, then press
ENTER.
See the Chapter 11 EDMAC operation specified in this manual.
6.3.1.9
CONFIG: MISC
MISC:
ADPCM-AUDIO-VOLUME
Select the parameter to edit using the [←] [→] arrow keys, then press ENTER.
CONFIG: MISC: G.703 CODE
TX G703 CODE = AMI
RX G703 CODE = AMI
Parameters may only be edited if the Interface Type is G.703.
Use the [←] [→] arrow keys to select the parameter to edit. Select either appropriate
G.703 code using the [↑] [↓] arrow keys, then press ENTER.
Note that the choices displayed here will depend on the G.703 interface type which has
been selected. The choices are:
•
•
•
EDMAC MODE = MASTER (IDLE/MASTER/SLAVE)
EDMAC ADDRESS = XXXX
An EDMAC MASTER is a unit which is local to the M&C computer, and which
passes messages, via the overhead, to a distant-end modem. The MASTER
address will always end in 0.
An EDMAC SLAVE is a unit which is not local to the M&C computer, which is
at the distant-end of a satellite link. The SLAVE EDMAC address will always
end in 1.
G.703-LINE-CODE IDR-ESC-TYPE
HDB3 (for E1 and E2 operation)
B8ZS ( for T1 and unbalanced T2 operation)
B6ZS (for balanced T2 operation)
HIGH-RATE-IBS-ESC
(AMI,B8ZS)
(AMI,B8ZS)
6–21
Revision 0
MN/CDM600L.IOM
