Chapter 17. Dst Setup; Initial Operation; Prior To Turning On Power - Comtech EF Data CDM-600L Installation And Operation Manual

This chapter describes the general setup of the modem in a DST using the front panel
keys. Detail operation of the modem is the same as specified in Chapters 1 through 16 of
this manual.
17.1

Initial Operation

CAUTION
17.1.1

Prior to Turning On Power

Note: Ensure DST system is installed properly and all connections all secure, except the
L-Band TX and RX IF connectors which are initially disconnected.
Observe the following steps:
Step
No.
1.
2.

Chapter 17. DST SETUP

Careful setup is necessary to prevent damage to electronic components.
Replacement of a component(s) may be the result.
DC voltages for BUC or LNB power may be present at the modem transmit
and receive IF connectors. Protect spectrum analyzers and other equipment
sensitive to DC voltage with a DC block, such as Weinshel Model 7003, to
prevent accidental damage.
Selection / Programming
Make sure prime power to the Modem is removed.
Verify the IFL L-Band cables are not connected to the
modem.
17–1
Menu Location
