CDM-600L Satellite Modem
Front Panel Operation
6.3.4.7

BUC

CURRENT
VOLT
CLASS
PWR
Amb
PLL
VER
6.3.5

STORE/LOAD

CONFIGURATION: 0 LOAD STORE EDIT
'AVAILABLE'
Select LOAD, STORE or EDIT using the [←][→] arrow keys, then press ENTER.
The user can store, load up to 10 different modem configurations, or record the date and
time of stored configurations in the non-volatile memory of the modem. These
configurations can be viewed using the [↑] [↓] arrow keys, and their names edited.
6.3.5.1 STORE/LOAD: OVERRIDE CONFIGURATION
CONFIGURATION: xx OVERRIDE: NO (YES/NO)
Select override using the [↑] [↓] arrow keys, then press ENTER.
BUC:CURRENT = 0000mA VOLT = 47.9V CLASS = N/A
PWR = N/A Amb = N/A PLL = N/A
If a BUC supply is installed, displays measured BUC load current.
If a BUC supply is installed, displays measured BUC supply voltage at the
TX-IF connector.
If BUC FSK is enabled, displays the output power rating of the BUC.
If BUC FSK is enabled, displays the output power as measured by the BUC
power monitor.
If BUC FSK is enabled, displays BUC ambient temperature in °C.
If BUC FSK is enabled, displays the fault status of the BUC PLL
synthesizers.
If BUC FSK is enabled, displays the M&C software version of the BUC.
VER = NA
6–36
Revision 0
MN/CDM600L.IOM
