CDM-600L Satellite Modem
Open Network Operations
9.2.1

IBS Clock/data recovery and De-jitter

Performs clock and data recovery on the G.703 format. Clock de-jitter and data
encoding/decoding is done as with the IDR configuration.
9.2.2

IBS Framing

Multiplexes/demultiplexes the primary data in compliance with the standard IESS-309
overhead ratio of 1/15 (4 overhead bytes per 60 data bytes) and provides the rate
exchanged transmit clock to the modulator portion of the base modem.
9.2.3

IBS Engineering Service Channel

Bi-directional processing of the components of the ESC channel, including the ASYNC
or SYNC EIA-232 data channel, and fault/alarm indications. Comtech EF Data plans to
offer a High Rate ESC option (not available at the time of writing – consult factory).
9.2.4

IBS Scrambling

Provides the synchronous scrambling/descrambling of the satellite-framed data specified
in IESS-309. Base modem scrambling/descrambling is disabled in this mode.
9.3

Drop and Insert

G.703
Satellite Data Rates Supported
(all have 16/15 overhead)
Terrestrial Framing Supported
Satellite Overhead Rate
Timeslot Selection Range
Plesiochronous Buffer Sizes
Buffer Clock Reference
Primary Data Rates Supported
1544 kbps SD, RD, DDO, IDI
2048 kbps SD, RD, DDO, IDI
N x 64 kbps
N = 1, 2, 3, 4, 5, 6, 8, 10, 12, 15, 16, 20, or 24 (T1)
N = 1, 2, 3, 4, 5, 6, 8, 10, 12, 15, 16, 20, 24, or 30 (E1-CCS)
N = 1, 2, 4, 6, 8, 12, 16, 24, 30 (E1-CAS)
G.732/G.733, G.704
16/15 of data rate per IESS-308 Rev. 6 and IESS-309 Rev. 3,
or higher
1 to 24 (all T1 modes)
1 to 30 (E1-CAS and E1-CCS)
Arbitrary order, non-contiguous available
Selectable size of 64 to 262,144 bits, in 16-bit steps (with
added limitations for G.704 frame boundaries)
Derived from Insert Data In (Insert Clock)
External, Rx (satellite) or Tx (Terrestrial)
