CDM-600L Satellite Modem
Front Panel Operation
6.3.1.10
CONFIG: REMOTE CONTROL
REMOTE CONTROL = LOCAL
Select LOCAL or REMOTE using the [↑] [↓] arrow keys, then press ENTER.
CONFIG: REMOTE CONTROL: INTERFACE
INTERFACE= RS-485-4W
Use the [←] [→] arrow keys to select the parameter to edit: Interface, Address or
Baudrate.
Edit the Interface type, Baudrate and each digit of the Address using the [↑] [↓] arrow
keys.
CONFIG: REMOTE CONTROL: CHAR FORMAT
PARITY:DATA-BITS:STOP-BITS = N81
Edit the I/O character format using the [↑] [↓] arrow keys. The options are:
If LOCAL is selected, the REMOTE CONTROL is disabled. Remote monitoring
is still possible.
If REMOTE is selected, then the following sub-menus will be displayed.
ADDRESS= 0001
For RS-485, the permitted address range is 1 to 9999.
Address 0 is reserved for universal addressing.
For RS-232, the Address is fixed at 0000.
N81
No parity
E72
Even parity
O72
Odd parity
(LOCAL,REMOTE)
(232,485-2,485-4)
BAUDRATE= 9600
(N81,E72,O72)
8 Data bits
1 Stop bit
7 Data bits
2 Stop bits
7 Data bits
2 Stop bits
6–23
Revision 0
MN/CDM600L.IOM
