Comtech EF Data CDM-600L Installation And Operation Manual page 83

CDM-600L Satellite Modem
Front Panel Operation
6.3.5.2 STORE/LOAD: EDIT CONFIGURATION
EDIT CONFIGURATION NUMBER 0x
Each configuration may have a name or description entered or edited using the [↑] [↓]
arrow keys, then press ENTER.
6.3.6 UTILITIES
UTILITIES:
LAMP
Select the Utilities parameter using the [←][→] arrow keys, then press ENTER
6.3.6.1 UTILITIES: SET-RTC
TIME: 12:00:00
To edit the time and date settings of the REAL-TIME CLOCK, select the digit to be
edited using the [←][→] arrow keys, change the value of the digit using the [↑] [↓] arrow
keys, then press ENTER.
IMPORTANT
6.3.6.2 UTILITIES: BRIGHTNESS
To edit the display BRIGHTNESS, use the [↑] [↓] arrow keys. Press ENTER when the
brightness is suitable. Note that the values of brightness that can be selected are 25%,
50%, 75% or 100%.
SET-RTC
1:1-MANUAL-SWITCH
EDIT REAL-TIME CLOCK:
Note that in accordance with international convention, the date is shown
in DAY-MONTH-YEAR format.
EDIT DISPLAY BRIGHTNESS:
100%
DISPLAY-BRIGHTNESS
EDIT-CIRCUIT-ID
DATE: 24/04/01
6–37
Revision 0
MN/CDM600L.IOM
.
