CDM-600L Satellite Modem
Connector Pinouts
5.12

Ground Connector

A #10-32 stud on the rear panel of the modem is used for connecting a common chassis
ground among equipment.
Note: The AC power connector provides the safety ground.
5–9
Revision 0
MN/CDM600L.IOM
