UM1878
1

Features

•
STM32L073VZT6 ultra-low-power Arm
featuring 192 Kbytes of Flash memory and 20 Kbytes of RAM in LQFP100 package
•
Four 5 V power supply options: power jack, ST-LINK USB connector, user USB FS
connector, or daughterboard
• Selectable MCU voltage: 3.3 V or adjustable from 1.7 V to 3.6 V
•
2.8-inch color TFT LCD with resistive touchscreen
• LCD glass 40 x 8 segments
•
On-board current measurement
•
IrDA transceiver
•
Pressure sensor
•
LC sensor metering
•
Touch-sensing linear sensor
•
User and reset push-buttons
•
4-direction joystick with selection button
•
Board connectors:
–
–
–
•
Board expansion connectors:
–
–
•
On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability:
mass storage, virtual COM port and debug port
• Comprehensive free software libraries and examples available with the STM32Cube
package
•
Support of a wide choice of integrated development environments (IDEs), including
IAR ™ , Keil
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
2 RS-232 with DB9
USB with Micro-B
microSD™ card interface
RF-EEPROM daughterboard
Extension connector for daughterboard or wrapping board
®
and GCC-based IDEs
®(a)
Cortex
UM1878 Rev 2
®
core-based microcontroller
Features
