Hardware layout and configuration
7.15
TFT LCD display
The 2.4" color TFT LCD is connected to SPI1 port of STM32L073VZT6. The LCD TFT
module is the MB895/S.
Pin
1
2
3
4
5
6
7
8
Voltage translators are implemented on SPI bus between the microcontroller
STM32L073VZT6 and LCD module to allow the LCD to be functional over the whole voltage
range of the microcontroller. A bidirectional voltage translator is used on SPI_MOSI PE15
because the LCD module has a specific mode in which it may send back information on this
line. The direction of this voltage translator is controlled by SPI_MOSI_DIR PH9. PE15 is
working as MOSI when PH9 is high or as MISO when PH9 is LOW.
7.15.1
Limitations
No exclusivity.
7.15.2
Operating voltage
The whole operating range of STM32L073VZT6 is: 1.65 V to 3.6 V.
7.16
User LEDs
Four general purpose color LEDs (LD 1, 2, 3, 4) are available as display devices.
LED LD1 (Green)
LED LD2 (Orange)
LED LD3 (Red)
LED LD4 (Blue)
26/64
Table 11. TFT LCD connector
2.4" TFT LCD connector CN16
Description
Pin connection
CS
PE10
SCL
PE13
SDI
PE15
RS
-
WR
-
RD
-
SDO
PE14
RESET
RESET#
User LEDs
PE4
PE5
PD1
PE7
Pin
V
9
10
VCI
11
GND
12
GND
13
BL_VDD
14
BL_Control
15
BL_GND
16
BL_GND
Table 12. User LEDs
Pin used
UM1878 Rev 2
Description
Pin connection
3.3V
DD
3.3V
GND
GND
5V
5V
GND
GND
comment
"low" = LED lighted
"low" = LED lighted
"low" = LED lighted
"low" = LED lighted
UM1878
