11 LAN Settings

The Call Recorder Single Digital has an Ethernet port. The network
interface supports the following protocols:
FTP server
•
SMTP client for sending email messages to a SMTP server
•
Telnet for remote configuration
•
NTP for automated adjustments of the system clock
•
A propriety protocol for streaming audio for remote monitoring
•
FTP server is used by the Call Recorder Access System for network access
to the database in the recorders and playback and archiving of
recordings. It can also be used to give other (custom) applications access
to the recordings in the recorder.
SMTP gives the recorder the ability to send emails. This has two
functions. The first one is that the recorder can send recordings as an
attachment to the user. The second is that the recorder can send status
updates about the system health, for example that the telephone line is
disconnected or that the system is ok.
Telnet give the possibility to a systems manager to access an internal
settings menu from remote.
The NTP (Network Time Protocol) is a great method to synchronise the
clock of the recorder with an external one somewhere on the network.
RTR monitoring is available for users of this special PC software. It will
be described later in this manual.
11.1

Network active

To begin the network configuration on the desktop model press:
Press the
•
Network active: No
Press CHANGE CHANGE to enable the network. CHANGE CHANGE
•
Press NEXT NEXT to save and move on to the next menu item. NEXT NEXT
•
Call Recorder Single Digital manual ©Vidicode 2011-2014
function key to enter the network settings.
CHANGE STOP
49
