RuggedSwitch™ User Guide

Administration Menu

The Administration command provides the menu shown in the following Figure.
My Switch
CTRL Z H l

Figure 2: Administration Menu

Configure IP Services

The Configure IP Services command provides the ability to change the IP
Address/mask, Gateway address, Inactivity Timeout, Telnet Sessions Allowed,
TFTP Server and SNMP Get Community parameters.
Note:
These parameters are not changed during a factory reload. The following figure shows
the settings as shipped from the factory.
My Switch
<CTRL> Z-Help S-Shell

Figure 3: IP Services Configuration Menu

IP Address Type

This parameter specifies if the IP configuration is static (i.e. configured through
this menu), or dynamically assigned. If dynamic IP configuration is chosen, the IP
Address, Subnet and Gateway fields will become unavailable for editing and will
not be displayed. These values will be loaded via Dynamic Host Configuration
Protocol (DHCP) and may be viewed using the "ipconfig" shell command.

IP Address

This parameter specifies the IP address of the switch.
Administration
Configure IP Services
Configure System Identification
Configure Passwords
Configure Time and Date
Configure SNMP Management Stations
S Sh ll
IP Services Configuration
IP Address Type
IP Address
Subnet
Gateway
Inactivity Timeout
Telnet Sessions Allowed
TFTP Server
SNMP Get Community
Static
192.168.0.1
255.255.255.0
5 min
8
Get Only
public
Admin Access
Admin Access
