CoS Configuration

CoS Parameter Ranges & Default Settings
The following set of tables lists default CoS configuration parameters for the unit.
Configuration Item
CoS Weighting
Default CoS (Per Port)
Inspect TOS (Per Port)
Priority to CoS Mapping (Per Access Priority)
DSCP to CoS Mapping (Per DSCP)
Normal Access Priority (Per Port)
High Access Priority (Per Port)

Classes Of Service Menu

The Classes Of Service menu is accessible from the main menu Classes Of
Service command.
My Switch
<CTRL> Z-Help S-Shell>

Figure 26: Classes Of Service Menu

Global CoS Parameters Menu

The Global CoS Parameters menu is accessible from the Classes Of Service menu.
My Switch
<CTRL> Z-Help S-Shell>

Figure 27: Global CoS Parameters Menu

CoS Weighting
During traffic bursts, frames queued in the switch pending transmission on a port
may have both high and normal priorities. This parameter specifies the weighting
algorithm for transmitting high priority CoS and normal priority CoS frames.
Some examples include:
1:1 - 1 high priority frame is transmitted for every normal priority frame
RuggedCom
Chapter 5 – Configuring Class of Service
Default Supported Values
Value
2:1 1:1, 2:1, 4:1, 6:1, 8:1, 10:1, 12:1, 1:0
Normal Normal, High
No No, Yes
Normal Normal, High
Normal Normal, High
0 0-7
4 0-7
Classes Of Service
Configure Global CoS Parameters
Configure Port CoS Parameters
Configure Priority to CoS Mapping
Configure DSCP to CoS Mapping
Configure CoS Access Priorities
Global CoS Parameters
CoS Weighting 2:1
Admin Access
Admin Access
