RuggedSwitch™ User Guide

View Ethernet Statistics

Ethernet statistics provides a continuously updated (once per second) view of the
traffic on all ports.
My Switch
Port
1
2
3
4
5
6
7
8

Figure 52: Ethernet Statistics Menu

This traffic view is useful when the origin and destination of a traffic flow needs
to be determined. The ErrorPkts field provides a sum total of all the individual
sources of port errors as described in the Ethernet Port statistics menu.

View Ethernet Port Statistics

Ethernet port statistics provide a continuously updated (once per second) detailed
view of the traffic on a single port.
My Switch
Select Port: 3
Statistics:
InOctets
OutOctets
InPkts
OutPkts
TotalInOctets
TotalInPkts
InBroadcasts
InMulticasts
CRCAlignErrors
OversizePkts
Fragments
Jabbers
<CTRL> Z-Help S-Shell

Figure 53: Port Statistics Menu

This traffic view is useful when the exact source of error or traffic mix needs to be
determined. The statistics are as described in the following tables.
Cumulative Statistics of Packet/Byte Counts
InOctets This counter is incremented once for every data octet of good packets (Unicast
+ Multicast + Broadcast) received.
OutOctets This counter is incremented for every data octet of a transmitted good packet.
Ethernet Statistics
State InOctets OutOctets
Up 53412 319576
Up 17600 15482
Down 0 0
Down 0 0
Down 0 0
Down 0 0
Down 0 0
Up 55068 70012
Ethernet Port Statistics
Link Status:
Link
Speed
Duplex
8436846
38272361
40811
190282
8442416
40860
439
3391
0
0
0
0
InPkts OutPkts
47 519
275 247
0 0
0 0
0 0
0 0
0 0
766 322
Up
100
Full
Collisions
LateCollisions
Pkt64Octets
Pkt65to127Octets
Pkt128to255Octets
Pkt256to511Octets
Pkt512to1023Octets
Pkt1024to1536Octets
DropEvents
OutBroadcasts
OutMulticasts
UndersizePkts
Admin Access
ErrorPkts
0
0
0
0
0
0
0
0
Admin Access
0
0
137413
53701
13792
5737
1540
18959
0
25259
119281
0
RuggedCom
