RMON History Samples Table Menu

History samples for a particular record in the RMON History Control Table are
displayed by selecting a particular record there and pressing <CTRL> V. The
index of the record will be included in the resulting menu title of the sample
screen.
The table will present a series of samples. The Sample number starts with one and
increases by one with each new log entry. The oldest samples are deleted in favour
of new samples when the allotted buckets are used.
The StartTime provides the system time when the measurement interval started.
The remaining fields provide the counts for each statistic as measured in the
sample period.
Statistics collection begins whenever the History Control record is created and
when the switch is initialized. As new samples are added, the window is
automatically updated.
My Switch
Sample
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
More right and below ...

Figure 56: RMON History Samples Table

RuggedCom
RMON History 1 Samples Table
StartTime DropEvents InOctets
0 days, 00:00:50 0
0 days, 00:00:54 0
0 days, 00:00:58 0
0 days, 00:01:02 0
0 days, 00:01:06 0
0 days, 00:01:10 0
0 days, 00:01:14 0
0 days, 00:01:18 0
0 days, 00:01:22 0
0 days, 00:01:26 0
0 days, 00:01:30 0
0 days, 00:01:34 0
0 days, 00:01:38 0
0 days, 00:01:42 0
0 days, 00:01:46 0
0 days, 00:01:50 0
0 days, 00:01:54 0
0 days, 00:01:58 0
Chapter 9 - Using Ethernet And RMON Statistics
InPkts
623 5
446 5
383 5
288 4
384 6
1217 10
192 3
193 3
192 3
256 4
367 4
128 2
192 3
192 3
629 5
502 4
256 4
192 3
Admin Access
InBroadcasts
2
1
2
2
1
8
1
0
1
2
2
0
1
1
1
1
2
1
