Virtual LANs Menu

The Virtual LANs menu is accessible from the main menu Virtual LANs
command. The VLAN menu will lead you to all the other available menus for
configuring and obtaining the status of VLANs.
My Switch
<CTRL> Z-Help S-Shell

Figure 20: Virtual LANs Menu

Static VLANs Menu

The Static VLANs menu is accessible from the Virtual LANs menu Configure
Static VLANs command. This menu presents currently configured VLANs. Edit
an existing VLAN configuration by selecting it using the up and down arrow keys
and pressing enter. Delete a VLAN by selecting an entry and pressing <CTRL
D>. Configure a new VLAN by entering <CTRL I>.
My Switch
<CTRL>

Figure 21: Static VLANs Menu

VID
Valid VLAN numbers lie in the range of 1 to 1000.
Note:
VLAN Name
Entering a meaningful name will associate this VLAN with its users.
Forbidden Ports
This parameter is used to forbid certain ports' membership in the VLAN. Trunk
ports listed here will not be members of the VLAN.
Virtual LANs
Configure Static VLANs
Configure Port VLAN Parameters
View VLAN Summary
Static VLANs
VID VLAN Name
1
2 SCADA IEDs
3 METERING IEDs
4 PROTECTION IEDs
Z-Help S-Shell D-PgDn U-PgUp I-Insert L-Delete
The switch reserves the first VLAN (VLAN 1) for management purposes.
Admin Access
Forbidden Ports IGMP
None On
None Off
None Off
3,6 On
