RuggedSwitch™ User Guide

Multicast Filtering Configuration

Multicast Filtering Parameter Ranges & Default Settings
The following set of tables lists default IGMP configuration parameters for the
switch.
Configuration Item
IGMP Mode
IGMP Query Interval
Router Ports
IGMP Operational Status (per VLAN)

Multicast Filtering Menu

The Multicast Filtering menu is available from the main menu Multicast Filtering
command.
My Switch
<CTRL> Z-Help S-Shell

Figure 44: Multicast Filtering Menu

IGMP Parameters Menu

IGMP parameters are configured from this menu. Note that the activation of
IGMP on a per-VLAN basis is configured using the Virtual LANs menu
Configure VLANs command.
My Switch
<CTRL> Z-Help S-Shell

Figure 45: IGMP Parameters Menu

Mode
This parameter sets the IGMP mode to active or passive.
In active mode the switch generates IGMP queries, if and when queries from a
multicast router are not detected. In passive mode the switch passively snoops
IGMP traffic and never sends IGMP queries.
Default Value Supported Values
Active Active, Passive
60 Seconds 10 to 3600 seconds
None A list of ports
Off Off, On
Multicast Filtering
Configure IGMP Parameters
View IP Multicast Groups
IGMP Parameters
Mode Active
Query Interval 60 s
Router Ports None
Admin Access
Admin Access
RuggedCom
