RuggedSwitch™ User Guide
6:1 - 6 high priority frames are transmitted for every normal priority frame
1:0 - transmit normal priority frames only after all high priority frames are sent

Port CoS Parameters Menu

The Port CoS Parameters menu is accessible from the Classes Of Service menu.
My Switch
CTRL Z H l

Figure 28: Port CoS Parameters Menu

Default CoS
The default CoS to assign frames received upon the port. Other criteria such as
TOS DSCP and MAC CoS also play a part in determining the final frame CoS.
Inspect TOS
Whether to prioritize frames on this port based upon TOS DSCP.

Priority to CoS Mapping Menu

The Priority to CoS Mapping menu is accessible from the Classes Of Service
menu.
My Switch
<CTRL> Z-Help S-Shell>

Figure 29: Priority to CoS Mapping Menu

CoS
This menu maps the priority field in an 801.1P or 802.1Q tag to a CoS.
Port CoS Parameters
Port Default CoS
1 Normal
2 Normal
3 Normal
4 Normal
5 Normal
6 Normal
7 Normal
8 Normal
S Sh ll
Priority to CoS Mapping
Priority
0
1
2
3
4
5
6
7
Inspect TOS
No
No
No
No
No
No
No
No
CoS
Normal
Normal
Normal
Normal
High
High
High
High
Admin Access
Admin Access
RuggedCom
