DSCP to CoS Mapping Menu

The DSCP to CoS Mapping menu is accessible from the Classes Of Service menu.
My Switch

Figure 30: TOS DSCP to CoS Mapping

CoS
This menu maps the TOS DSCP from a IP frame to a CoS.

CoS Access Priorities Menu

The CoS Access Priorities menu is accessible from the Classes Of Service menu.
My Switch
<CTRL> Z-Help S-Shell>

Figure 31: CoS Access Priorities Menu

Normal Access Priority
When frames that were originally received untagged are transmitted from a tagged
port the switch will insert an 802.1Q VLAN tag priority field based upon the
frame's CoS. The port will insert this parameters value when the frame is
configured for normal priority CoS.
High Access Priority
The port will insert this parameters value when the frame is configured for high
priority CoS.
RuggedCom
DSCP to CoS Mapping
DSCP
0
1
2
3
4
5
6
7
8
9
More below ...
CoS Access Priorities
Port Normal Access Priority
1 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
Chapter 5 – Configuring Class of Service
Admin Access
CoS
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
High Access Priority
4
4
4
4
4
4
4
4
Admin Access
39
