RSTP Configuration

Bridge and Port Parameter Ranges & Default Settings
The following set of tables lists default STP configuration parameters for the unit.
For each parameter the parameter name, recommended setting and possible range
are included.
Bridge Parameters
Configuration Item
State
Version Support
Hello Time
Max Age Time
Transmit Count
Forward Delay
Cost Style
Port Parameters
These configurable items apply to all ports.
Configuration Item
Enabled
Priority
STP Cost
RSTP Cost
Edge Port
Point to Point
RuggedCom
Default Value
Enabled
STP and RSTP
2 seconds
20 seconds
10
15 seconds
Costs follow STP (16 bit) style
Default Value
Port Enabled
128
Auto
Auto
False
Auto
Chapter 6 – Configuring Rapid Spanning Tree
Supported Values
Disabled, Enabled
STP, STP and RSTP
1 to 10 seconds
6 to 40 seconds
3 to 10
4 to 30
Costs follow STP (16 bit) style, Costs follow
RSTP (32 bit) style
Supported Values
Disabled, Enabled
0, 16, 32, 48, 64, 80, 96, 112, 128, 144, 160,
176, 194, 208, 224, 240
Auto, 0 to 65535
Auto, 0 to 2147483647
False, True
Auto, False, True
