RuggedSwitch™ User Guide
RMON-MIB (RFC 2819)
etherStatsDropEvents
etherStatsOctets
etherStatsPkts
etherStatsBroadcastPkts
etherStatsMulticastPkts
etherStatsCRCAlignErrors
etherStatsUndersizePkts
etherStatsOversizePkts
etherStatsFragments
etherStatsJabbers
etherStatsCollisions
etherStatsPkts64Octets
etherStatsPkts65to127Octets
etherStatsPkts128to255Octets
etherStatsPkts256to511Octets
etherStatsPkts512to1023Octets
etherStatsPkts1024to1518Octets The total number of received packets that where between 1024
The number of received packets that are dropped due to lack of
receive buffers.
The number of bytes in good packets
(Unicast+Multicast+Broadcast) and dropped packets received.
The number of good packets (Unicast+Multicast+Broadcast) and
dropped packets received.
The number of good Broadcast packets received.
The number of good Multicast packets received.
The number of packets received which meet all the following
conditions: packet data length is between 64 and 1536 bytes
inclusive, packet has invalid CRC, Collision Event has not been
detected, Late Collision Event has not been detected.
The number of received packets which meet all the following
conditions: packet data length is less than 64 bytes, Collision
Event has not been detected, Late Collision Event has not been
detected, packet has valid CRC.
The number of packets received with data length greater than
1536 bytes and valid CRC.
The number of packets received which meet all the following
conditions: packet data length is less than 64 bytes, or packet
without, SFD and is less than 64 bytes in length, Collision Event
has not been detected, Late Collision Event has not been detected,
packet has invalid CRC.
The total number of packets received that were longer than 1518
bytes and had either a bad Frame Check Sequence or Alignment
Error.
The best estimate of the total number of collisions on this
Ethernet segment.
The total number of received packets that where 64 bytes long.
The total number of received packets that where between 65 and
127 bytes long.
The total number of received packets that where between 128 and
255 bytes long.
The total number of received packets that where between 256 and
511 bytes long.
The total number of received packets that where between 512 and
1023 bytes long.
and 1518 bytes long.
