RuggedSwitch™ User Guide

The Structure of the User Interface

The user interface is organized as a series of menus with an escape to a command
line interface (CLI) shell. Each menu screen presents the switch name (as proved
by the System Identification parameter), Menu Title, Access Level, Alarms
indicator, Sub-Menus and Command Bar.
Sub-menus are entered by selecting the desired menu with the arrow keys and
pressing the enter key. Pressing the escape key ascends to the parent menu.
System Identification
My Switch
<CTRL> Z-Help S-Shell X-Logout
Command Bar

Figure 1: Main Menu With Screen Elements Identified

The command bar offers a list of commands that apply to the currently displayed
menu. These commands include:
• <CTRL> Z to display help on the current command or data item
• <CTRL> S to switch to the CLI shell
• <CTRL> U/D to jump to next/previous page of a status display
The main menu also provides a <CTRL> X command, which will terminate the
session.
Menu Name
Main Menu
Administration
Port Configuration and Status
Ethernet Statistics
S panning Tree
Virtual LANs
Classes of Service
MAC Address Tables
Multicast Filtering
Diagnostics
Sub-Menus
Access Level/Alarms Indicator
Admin Access
RuggedCom
