Remote Control
Packed Configuration Status:
Configuration Confirmation:
Status
Packed Packed Maint Status:
Maintenance Confirmation:
Status
14
KPA080 Ku-Band Solid-State Power Amplifier
<DEV/PACRCS_'cr'
>DEV/PACRCS_aabcdeffgh'cr'' lf']
<DEV/PACRMS_'cr'
>DEV/PACRMS_aabbccddeeffgghhhiiijjj'cr''
lf']
Where:
aa = # of 0.25 dB steps in Hex above 0dB
(0 to 120)
b = 1 = Amplifier is On; 0 = Off
c = 1 = TX On; 0 = Off
d = 1 = unit ONLINE; 0 = OFFLINE
e = 1 = Redundancy On; 0 = Redundancy
Off
ff = SSPA No. = BU = 01 or 02 ( e = 0, ff =
00)
g = A = Auto Mode; M = Manual Mode
h = 1 = Auto Recovery enabled; 0 if
disabled
Where:
aa = + 28 VDC supply, 100mV per count
above 10.0V in Hex
bb = + 12 VDC supply scaled 100 mV per
count in Hex
cc = - 12 VDC supply scaled 100mV per
count in Hex
dd = + 5 VDC supply scaled –100mV per
countin Hex
ee = - 5 VDC supply scaled –100mV per
count in Hex
ff = + 9 VDC supply #1 scaled 100 mV per
count in Hex
gg = + 9 VDC supply #2 scaled 100mV per
count in Hex
hhh = Signed temperature in degrees C
(-10 to +95)
iii = RF forward power, 0.1 dBm steps
above 20.0 dBm in Hex
jjj = RF reverse power, 0.1 dBm steps
above 15.0 dBm in Hex
