KPA080 Ku-Band Solid-State Power Amplifier

2.2.2

Cable Connections

The cable signal functions are shown in Table 2-1.

2.2.3

Comtech EFData SSPAs are easily configured for redundant systems by using one of the

optional Redundant Cable Kits. These kits include all the necessary controls, semi-rigid,

and waveguide cabling, and appropriate waveguide/coax switches and terminations.

Figure 2-1 shows the typical 1:1 installation and Table 2-2 shows the associated parts list.

The primary and backup SSPAs shall be installed next to each other in a standard 19-inch

(48 cm) equipment rack. Because of the configuration of the dual WG-Coax Switch, the

upper SSPA will always act as the backup.

Rev. 0

Connector

SSPA RF Input (RF). Mating connector: Type SMA Female

SSPA RF Output (RF). Mating connector: WR75G

AC Prime Power (Cord provided with SSPA)

Redundant Loop Interface (for use in redundant configurations)

Customer Discrete Control

COM 1: Serial Communications Interface, EIA-232 or EIA-485

Waveguide Switch Interface (for use in redundant configurations)

Function

communications links

Mating connector: Type DB9M

Installation

2-3
