Remote Control
5.9.4

Status Commands

Configuration Configuration Status:
Status Confirmation:
Maintenance Maintenance Status:
Status Confirmation:
FET Status FET Status:
Confirmation:
12
KPA080 Ku-Band Solid-State Power Amplifier
<DEV/RCS_'cr'
>DEV/RCS_'cr'
ATT_yy.yy'cr'
AMP_nnn'cr'
TX_nnn'cr'
ONL_nnn'cr'
RED_xx_y'cr'
AFR_nnn'cr'
<DEV/RMS_'cr'
>DEV/RMS_'cr'' lf']
V+28_xx.x'cr'
V+12xx.x'cr'
V-12_xx.x'cr'
V+5_x.x'cr'
V–5_x.x'cr'
V+9_1_xx.x'cr'
V+9_2_xx.x'cr'
TEMP_xx'cr'
FPWR_xx.x'cr'
RPWR_xx.x'cr'' lf']
<DEV/RFS_'cr'
>DEV/RFS_'cr'
FET1_xxx'cr'
FET2_x.x'cr'
FET3_x.x'cr'
FET4_x.x'cr'
FET5_x.x'cr'
FET6_x.x'cr'
FET7_x.x'cr'
FET8_x.x'cr'
FET9_x.x'cr'
FET10_x.x'cr'
FET11_x.x'cr'
FET12_x.x'cr'
FET13_x.x'cr'
FET14_x.x'cr'
FET15_x.x'cr'
FETxx_x.x'cr'
FETyy_x.x'cr'_x.x'cr'
FET27_x..x'cr''lf']
Where:
Attenuator
Amplifier – On/Off
Transmit – On/Off
Online – On/Off
See Note.
Auto Flt Recoverty – On/Off
Notes:
1. If Redundancy is Off, xx_y = Off,
else if Redundancy is On the xx
field indicates the SSPA
designation, either BU (Backup)
01 or 02.
2. If xx is either 01 or 02 then the y
field indicates the Auto/Manual
status, either A if Auto or M if
manual.
3. If xx field is BU, the y field
indicates the pripority SSPA,
either 1 if SSPA #1 is high
priority or 2 if SSPA #2 is high
priority.
4. For 1:1 systems prority is
always #1.
Where:
+28 VDC Supply
+12 VDC Supply
–12 VDC Supply
+5 VDC Supply
–5 VDC Supply
9 VDC Supply #1
9 VDC Supply #2
Temperature
RF Forward Power (dBm)
RF Reflected Power (dBm)
Where :
FET1 current in milliamps
FET2 current in milliamps
FET3 current in amps
FET4 current in amps
FET5 current in amps
FET6 current in amps
FET7 current in amps
FET8 current in amps
FET9 current in amps
FET10 current in amps
FET11 current in amps
FET12 current in amps
FET13 current in amps
FET14 current in amps
FET15 current in amps
FETxx current in amps
FETyy current in amps
FET27 current in amps
Note: FETS from 1 to 27.
