Comtech EF Data KPA080 Installation And Operation Manual page 64

KPA080 Ku-Band Solid-State Power Amplifier
Utility Status Utility Status:
Confirmation:
Alarm Status Alarm Status:
Confitmation:
Summary Alarm Summary Alarm:
Status Confirmation:
Terminal Status Configuration Status:
Change Confirmation:
Rev. 0
<DEV/RUS_'cr'
>DEV/RUS_'cr'
COMM_aaaaaa'cr'
ADD_xxx'cr'
BR_nnnn'cr'
PAR_nn'cr'
CON_xx'cr'
LCD_xx'cr'' lf']
<DEV/RAS_'cr'
>DEV/RAS_'cr'
+28_xx'cr'
+12_xx'cr'
–12_xx'cr'
+5_xx'cr'
–5_xx'cr'
+9_1_xx'cr'
+9_2_xx'cr'
TEMP_xx'cr'
SHTD_xx'cr'
FAN1_xx'cr'
FAN2_xx'cr'' lf']
<DEV/SAS_'cr'
>DEV/SAS_xx'cr'' lf']
<DEV/TSC_'cr'
>DEV/TSC_nnn'cr'' lf']
Remote Control
Where:
EIA-232 or EIA-485
Address (001 to 255)
Baud Rate (300 to 9600)
Parity (OD or EV)
LCD Contrast (0 to 30)
LCD Brightness (0 to 30)
Where: xx = OK or FT
+28 VDC Fault
+12 VDC Fault
-12 VDC Fault
+ 5 VDC Fault
– 5 VDC Fault
+ 9_1_xx'cr'
+ 9_2_xx'cr'
TEMP_xx'cr'
Over Temperature Shutdown
FAN1_xx'cr'
FAN2_xx'cr'' lf']
Note: A temperature fault is indicated if the
unit is ≤ -20°C or ≥ 85°C. This creates a
summary fault and will cause the unit to
mute itself and switchover to the back-up
unit. However, the 9V supply to the FET
transistors will remain on until the unit
reaches the thermal shutdown
temperature of ≥ 90°C. For protection
reasons, the unit will shutdown the 9V
supply to the power transistors at
temperatures at ≥ 90°C.
Where: xx = Ok or FT
Summary Alarm is set to Fault (FT), if any
of items in Alarm Status are faulted.
Where: nnn = Yes or No
The TSC_ command can be used to
determine if the status of the terminal has
changed since it was last polled. If any of
the parameters listed in the RCS or RUS
commands have changed as a result of
user oprerations or if any new fault
conditions occur the TSC_ command will
return YES. The TSC_ command will then
continue to return YES until any of the
following commands are received: RCS_,
RUS_, RAS_, PACRCS_, PACRUS_, or
PACRAS_.
13
