Scan Length

The menu item determines how much of the label will be scanned during the
RFID calibration procedure.
Minimum
Maximum
Factory Default
IMPORTANT

Tag Length

This menu item selects the number of bytes in the EPC block within the RFID
tag memory.
Minimum
Maximum
Factory Default

EPC Address

This menu item selects the starting location of the EPC block within the RFID
tag memory.
Minimum
Maximum
Factory Default

Diagnostics Submenu

The following items are in the RFID > Diagnostics section and used to check correct behavior with the RFID
system or the tags being used.

Read Tag

This executable menu reads the tag in range of the internal RFID coupler
and reports the tag data to the debug port and momentarily displays it on the
control panel's LCD. It is primarily intended for development verification by
checking that the system is working.
IMPORTANT
24
RFID > Custom Tag > Start Position
0.0 inches
5.0 inches
3.0 inches
The units display in inches or millimeters, depend-
ing on SYSTEM > Control > Media Units.
RFID > Custom Tag > Tag Length
8
32
30
RFID > Custom Tag > EPC Address
0
32
0
RFID > Diagnostics > Read Tag
This menu item does not position the RFID tag
over the coupler. Make sure to position the tag
over the coupler to receive an accurate reading.
