The Statistics submenu is general read-only and used to gather and report statistics on how the RFID
system is reporting on print jobs sent to the printer. Those items are described starting on page 26.
RFID
Diagnostics
Configuring
Configuring the RFID is done by selecting the RFID icon
equipped with a default setting for each configuration option, and it works without having to change any of
these options. However, in some cases it is necessary to adjust these options, which are described below.
IMPORTANT If you are unable to select the RFID icon or the icon is grey, then the RFID is not
properly installed. Refer to Section "Printronix Customer Support Center" for help
on how to solve this problem.
IMPORTANT If you make any changes to the default configuration menu items, you will be
prompted to save the configuration. See "Auto Save Configuration" in the
Administrator's Manual.

Enabling and Disabling

Software can automatically detect an installed RFID when the printer is powered up. If the printer is
powered up with Configs > Control > Power-Up Config set to "Factory", the RFID icon can be selected and
RFID > Control > RFID Active is set to "Enable".
If Power-Up Config. is not set to Factory, the RFID icon can be selected, but RFID > Control > RFID Active
is set to "Disable". Set this menu to "Enable" and save the configuration as described in the Administrator's
Manual. In the same manner, the RFID can be disabled.

Checking Firmware Revision

For troubleshooting purposes, you may need to reference the RFID firmware revision number. This can be
found in two different places within the Settings section:
•
RFID > Statistics > RFID Reader F/W.
•
TOOLS > About > RFID Reader F/W.
Figure 4 RFID Diagnostics, Statistics Submenus
Read Tag
Read
Tag & Eject
Tag Write Tag Failed
Statistics
Count
Read Only
Read Only
the RFID
Read Tag Read
TID ID
Read Only
Write
ECP with 2s
Tag Void Tag Read
Count Count Count
Read Only Read Only
within the Settings section. The RFID comes
Tag
PC PC
Read Only
Write
ECP with 1s
Clear Tag RFID Reader
Stats F/W
Read Only
