EPC (if the EPC value has changed from its factory state). The PC value to be programmed for each of the
supported EPC lengths is shown in Table 4.

Overstrike Error Messages

When an error occurs with the RFID functions within a job, the user can choose different styles of Overstrike
Style, including having the error printed on the label per Table 5. The x in the error messages represents a
number code that identifies the area in the printer software or RFID encoder where the failure occurred.
Error Message
Tag R/W Err x
Check media
Tag Comm Err x
Check cable
Precheck Fail x
Check media
Table 4 EPC/USR Lengths and PC Values
EPC Length USR Length
96 512
112 448
128 448
144 448
160 448
176 384
192 384
208 384
224 384
240 320
256 320
Table 5 Printed Overstrike Error Messages
The printer software attempted to write to or read from the
RFID tag, but the RFID encoder indicated that the tag could
not be written to or read from.
The printer software temporarily lost communication with the
RFID encoder, or communication between the printer soft-
ware and the RFID encoder was not synchronized and had to
be forced.
This failure occurs only when the Precheck Tags is enabled.
It indicates that the RFID tag was automatically failed since it
did not contain the correct pre-programmed quality code.
PC Value
0x3000
0x3800
0x4000
0x4800
0x5000
0x5800
0x6000
0x6800
0x7000
0x7800
0x8000
Explanation
