Evaluation Board User Guide

ORDERING INFORMATION

EVAL-RS485HDEBZ BILL OF MATERIALS
Table 3.
Quantity Reference Designator
1 C1
2 C2, C4
1 C3
6 A, B, DE, DI, RE, RO
1 GND
1 J1
2 J3, J5
1 LK1
1 LK2
2 LK3, LK4
2 R1, R2
1 R3
2 RT1, RT2
1 U1
1 VCC
Table 4. EVAL-RS485HDEBZ
Enhanced ESD, 3.3 V Supply
ADM3072E ADM3483E
ADM3075E ADM3485E
ADM3078E ADM3486E
Select the appropriate U1 devices in addition to
part number for SOIC devices, for example, ADM3072EARZ.
Description
Capacitor, 100 nF, 0805
Not placed/optional
Capacitor, 10 µF, Case B
Test point, yellow
Test point, black
2-way terminal block
4-way terminal block
8-pin (4 × 2) 0.1" header and shorting block
6-pin (3 × 2) 0.1" header and shorting block
Jumper Block, 2 pin, 0.1" spacing
Not placed/optional
Resistor, 0 Ω, 0805
Resistor, 120 Ω, 0805
8-lead SOIC (not placed)
Test point, red
Options for U1(Half-Duplex RS-485 Transceivers)
Enhanced ESD, 5 V Supply
ADM483E
ADM485E
ADM487E
ADM1487E
EVAL-RS485HDEBZ
Supplier/Part Number
Multicomp/MCCA000274
Not applicable
Kemet/B45196H3106K209
Vero Technologies/20-313140
Vero Technologies/20-2137
Lumberg/KRM 02
Lumberg/KRM 04
Harwin/M20-9953646 and Harwin/M7566-05
Harwin/M20-9953646 and Harwin/M7566-05
Harwin/M20-9990246 and Harwin/M7566-05
Not applicable
Vishay Draloric/CRCW08050000Z0EA
Multicomp/MC 0.1W 0805 1% 120R
Analog Devices, Inc./see Table 4
Vero Technologies/20-313137
Standard, 3.3 V Supply
ADM3483
ADM3485
ADM3493
when ordering. Ensure that the device ordered includes an R in the
Rev. 0 | Page 13 of 16
UG-543
Standard, 5 V Supply
ADM1485 ADM4850
ADM1486 ADM4851
ADM483 ADM4852
ADM485 ADM4853
