UG-543
EVAL-RS485FD8EBZ BILL OF MATERIALS
Table 5.
Quantity Reference Designator
1 C1
2 C2, C4
1 C3
6 A, B, DI, RO, Y, Z
1 GND
2 J1, J2
1 J3
2 LK1, LK2
2 R1, R2
1 R3
2 RT1, RT2
1 U1
1 VCC
Table 6. EVAL-RS485FD8EBZ
Enhanced ESD, 3.3 V Supply
ADM3071E ADM3488E
ADM3074E ADM3490E
ADM3077E
Select the appropriate U1 devices in addition to
part number for SOIC devices, for example, ADM3071EARZ.
Description
Capacitor, 100 nF, 0805
Not placed/optional
Capacitor, 22 µF, Case C
Test point, yellow
Test point, black
2-way terminal block
6-way terminal block
Jumper Block, 2 pin, 0.1" spacing
Not placed/optional
Resistor, 0 Ω, 0805
Resistor, 120 Ω, 0805
8-lead SOIC (not placed)
Test point, red
Options for U1(Full-Duplex RS-485 Transceivers, 8-Lead SOIC)
Enhanced ESD, 5 V Supply
ADM1490E
EVAL-RS485FD8EBZ
Rev. 0 | Page 14 of 16
Evaluation Board User Guide
Supplier/Part Number
Multicomp/MCCA000274
Not applicable
AVX/TAJC226K016RNJ
Vero Technologies/20-313140
Vero Technologies/20-2137
Lumberg/KRM 02
Lumberg/KRM 06
Harwin/M20-9990246 and Harwin/M7566-05
Not applicable
Vishay Draloric/CRCW08050000Z0EA
Multicomp/MC 0.1W 0805 1% 120R
Analog Devices/see Table 6
Vero Technologies/20-313137
Standard, 3.3 V Supply
ADM3488
ADM3490
when ordering. Ensure that the device ordered includes an R in the
Standard, 5 V Supply
ADM4854 ADM4857
ADM4855 ADM488
ADM4856 ADM488A
