Evaluation Board User Guide
EVAL-RS485FDEBZ BILL OF MATERIALS
Table 7.
Quantity Reference Designator
1 C1
1 C2
2 C3, C4
6 A, B, DE, DI, RE, RO, Y, Z
1 GND
1 J1
1 J2
1 J3
1 LK2
1 LK3
2 LK5, LK6
2 R1, R2
1 R3
2 RT1, RT2
1 U1
1 VCC
Table 8. EVAL-RS485FDEBZ
Enhanced ESD, 3.3 V Supply
ADM3070E ADM3076E
ADM3073E ADM3491E
Select the appropriate U1 devices in addition to
part number for SOIC devices, for example, ADM3070EARZ.
Description
Capacitor, 22 µF, Case C
Capacitor, 100 nF, 0805
Not placed/optional
Test point, yellow
Test point, black
2-way terminal block
4-way terminal block
6-way terminal block
8-pin (4 × 2) 0.1" header and shorting block
6-pin (3 × 2) 0.1" header and shorting block
Jumper Block, 2 pin, 0.1" spacing
Not placed/optional
Resistor, 0 Ω, 0805
Resistor, 120 Ω, 0805
14-lead SOIC (not placed)
Test point, red
Options for U1(Full-Duplex RS-485 Transceivers, 14-Lead SOIC)
Enhanced ESD, 5 V Supply
ADM1491E
EVAL-RS485FDEBZ
Supplier/Part Number
AVX/TAJC226K016RNJ
Multicomp/MCCA000274
Not applicable
Vero Technologies/20-313140
Vero Technologies/20-2137
Lumberg/KRM 02
Lumberg/KRM 04
Lumberg/KRM 06
Harwin/M20-9953646 and Harwin/M7566-05
Harwin/M20-9953646 and Harwin/M7566-05
Harwin/M20-9990246 and Harwin/M7566-05
Not applicable
Vishay Draloric/CRCW08050000Z0EA
Multicomp/MC 0.1W 0805 1% 120R
Analog Devices/see Table 8
Vero Technologies/20-313137
Standard, 3.3 V Supply
ADM3491
when ordering. Ensure that the device ordered includes an R in the
Rev. 0 | Page 15 of 16
UG-543
Standard, 5 V Supply
ADM489
ADM489A
