Power supply unit

AXEL LITE, as the other LITE Line CPU modules, embeds all the
elements required for powering the unit, therefore power sequencing is
self-contained and simplified. Nevertheless, power must be provided
from carrier board, and therefore users should be aware of the ranges
power supply can assume as well as all other parameters. For detailed
information, please refer to Section 5.1 Power Supply Unit (PSU) and
recommended power-up sequence.
3.7

CPU module connectors

All interface signals AXEL LITE provides are routed through SODIMM
DDR3 204 pin (named J2). The dedicated carrier board must mount the
mating connector and connect the desired peripheral interfaces
according to AXEL LITE pinout specifications.
For mechanical information, please refer to Section 4 (Mechanical
specifications). For pinout and peripherals information, please refer to
Sections 6 (Pinout table) and 7 (Peripheral interfaces).
