AXEL LITE Hardware Manual
ECSPI5_SS1
ECSPI5_SS2
ECSPI5_SS3
7.8
I²C
Three I²C channels are available on AXEL LITE to provide an interface
to other devices compliant with Philips Semiconductors Inter-IC bus (I2C-
bus™) specification version 2.1. The I²C ports support standard mode
(up to 100K bits/s) and fast mode (up to 400K bits/s).
7.8.1
I²C1
The following table describes the interface signals:
I2C1_SCL
I2C1_SDA
7.8.2
I²C2
The I²C2 bus is used for connecting the i.MX6 SOC to the PMIC. The
following table describes the interface signals:
I2C2_SCL
I2C2_SDA
7.8.3
I²C3
The following table describes the interface signals:
Pin name
Conn.
Pin
J2.63
J2.79
J2.65
J2.81
J2.67
Pin name
Conn.
Pin
J2.76
J2.181
J2.74
J2.195
Pin name
Conn.
Pin
J2.101
J2.103
Function
Chip select 1 signal
Chip select 2 signal
Chip select 3 signal
Function
I2C clock
I2C data
Function
I2C clock
I2C data
October, 2016
v. 0.9.5
Notes
Notes
Notes
51/63
